BDB12F40WVI

Design your light! Modular Architectural Downlight Range

BDB12F40WVI

Design your light! Modular Architectural Downlight Range

Product data

CRI
CRI>90
IP Rating
IP65
Adjustability
Not adjustable
Input
220-240V AC
Insulation Coverable
No
Cut Out
65-78
Beam Angle
50°
Building Regulations
Part B, C, E, P & L
Ceiling Joist Approvals
Solid Timber 30/60/90min, I-Joist 30min, Metal Web 30min
Wattage Range
9.6W
CCT Range
4000K
Lumens Range
725
lm/W Range
76
Colour / Finish
Matt Black
Dimmable Option
1-10V
Warranty
7 years
Energy Class
F
Reflector Finish
Black

About the BDB12F40WVI

More than a century of design and innovation helped inspire the creation of the luxurious architectural 1901 range, for when only the best will do.1901 is both contemporary and classic, with a focus on premium fittings, a high-quality performance and easy integration into control systems. Perfect for luxury residential and hospitality projects, 1901 showcases an aesthetically simple, low-glare luminaire design, with market-leading technical performance. The detailed fittings come in a variety of stylish options including a choice of bezels, adjustability, colour temperatures, beam angles, dimming methods, and IP ratings to perfectly complete the look of any interior design project. Simply configure your product to find the relevant product code. The range is engineered to be as easy to use as possible and can fit seamlessly into the installation and commissioning stages of a lighting project.

Features & Benefits

Available in IP65 for various applications

Mains, 1-10V & DALI-2 dimmable options

CRI 80 providing true colour appearance

The 1901 family consists of a pendant, spot light and downlight all with a consistent design language

Use our product selector to choose from 1,800 different combinations

Designed & assembled in Northampton UK

Fixed, Adjustable, Round, Square, Trimless options available

Emergency options available

Fire-rated to 30 minutes for us in Solid timber, I-Joist and Metal Web ceiling joists

Integrated LED using premium components to achieve 70,000 hours/60 years lifetime
